Carousel

Carousel shows a scrollable collection of mostly-visual items that change size as they move through the container. One component covers all six layouts Material specifies.

import { Button, Carousel } from '@language-lit/material3-expressive'
import '@language-lit/material3-expressive/styles.css'

// Multi-browse: many items at once, for quick browsing.
<Carousel
  aria-label="Recent photos"
  preferredItemWidth={186}
  items={photos.map((photo) => ({
    key: photo.id,
    label: photo.title,
    content: <img src={photo.src} alt="" />,
    onActivate: () => open(photo),
  }))}
/>

// Hero: one large item with a preview of what is next.
<Carousel aria-label="Featured" layout="centeredHero" items={featured} />

// Uncontained: same-size items that flow past the edge.
<Carousel aria-label="Articles" layout="uncontained" itemWidth={240} items={articles} />

// Multi-aspect ratio: each item keeps its own shape.
<Carousel
  aria-label="Clips"
  layout="multiAspect"
  items={clips.map((clip) => ({ key: clip.id, content: <video src={clip.src} />, aspectRatio: clip.ratio }))}
/>

Contract

items is the collection. Each item takes a key, its visual content, and optionally a label, onActivate, href, and disabled. An item with onActivate renders a real button and one with href a real a, so Space/Enter activation and the browser's scroll-into-view on focus come from the platform rather than from key handling.

layout selects the arrangement and defaults to "multiBrowse":

preferredItemWidth is a target, not a guarantee: the arrangement adjusts small items first, then medium ones, and only then the large width, so a whole number of items fits the container. minSmallItemWidth and maxSmallItemWidth bound the small item and default to the specified 40–56px range.

It is also the layout's only responsive lever, and it is yours to move. The arrangement adds items as the container grows — at a fixed 186 it fits three items at compact widths and eight at 1440px — but it does not grow the items themselves. Material's guidelines put compact at window widths under 600dp, expect up to three items there, and expect a growing window to both add items and scale them up. Only the first of those falls out of the algorithm, so raise preferredItemWidth at wider breakpoints if you want the second. The prop is a plain number, so a window-size-class hook or a ResizeObserver is enough to drive it. There is no specified ramp to copy: the first-party Compose sample hard-codes 186dp at every window size, which is why the examples here do the same.

One consequence is worth expecting rather than debugging. Whenever the arrangement fits more than one large item, those keylines share a size, so an item crosses them without resizing and only closes into its frame at the trailing edge. That is the arrangement working as specified — the browse region is stable and the resizing happens at the edges — and it is why a wide multi-browse carousel does not animate like a narrow one.

scroll chooses between the specification's two named behaviors and defaults to the one it recommends for the layout: "snap" everywhere except the two uncontained layouts, which default to "free". The full-screen layout requires snapping, so leave it alone there.

currentItem, defaultCurrentItem, and onCurrentItemChange track the item at a focal position. Setting currentItem scrolls to it; scrolling reports the nearest item back. itemSpacing overrides the gap.

The carousel needs an accessible name, so pass aria-label or aria-labelledby. Everything else on a div passes through, and the ref is the scroll container.

Adaptive item content

Items report their current width, so content can adapt without re-rendering. data-m3e-size is large, medium, or small on each item, and content marked data-m3e-carousel-hide fades out as the item narrows past the width that content needs:

<Carousel
  aria-label="Albums"
  preferredItemWidth={186}
  items={albums.map((album) => ({
    key: album.id,
    label: album.title,
    content: (
      <>
        <img src={album.cover} alt="" />
        <figcaption>
          <span data-m3e-carousel-hide="medium">{album.title}</span>
          <span data-m3e-carousel-hide="small">{album.year}</span>
        </figcaption>
      </>
    ),
  }))}
/>

That is Material's own rule: the large item shows the full title, the medium item hides it, the small item abbreviates the label. It is a fade rather than a switch, because that is what the reference does — a title is pinned to the masking edge and faded out as the item becomes too small for it.

The attribute's value picks how long content survives, not a hard cutoff: "medium" content is opaque on a focal item and gone by the middle of the range, "small" content is opaque by that middle and gone at the narrowest visible item. So a title leads its label out, and each transition is a fade you can watch rather than a switch.

If you want text to stay put rather than be cropped as it fades, translate it by --m3e-carousel-item-inset-start, as the reference pins its title. Prefer a translation to padding: padding changes the content's own width, and content wide enough to exceed the arrangement's item size is content the engine cannot place.

The exact pixel widths are available too, as --m3e-carousel-item-current-size, --m3e-carousel-item-min-size, and --m3e-carousel-item-max-size.

One caution if you use those numbers directly: --m3e-carousel-item-min-size mirrors the Compose value, which counts the anchor keylines — the slivers parked off screen at around 10px. It is not the narrowest item you can see, so normalising a size against it will class almost everything as medium. data-m3e-size already does the classification against the small keyline; prefer it.

Content is clipped to the item, never accommodated by it: an item is exactly the arrangement's width, because the snap offsets are derived from that width. So text that must stay readable as an item narrows should be padded by the mask insets, --m3e-carousel-item-inset-start and --m3e-carousel-item-inset-end, which is what they are exposed for — otherwise it is cropped mid-glyph rather than moved.

Show all — the accessibility requirement

On a vertically scrolling page, a horizontal carousel needs a route to every item that does not involve horizontal scrolling. Material asks for a Show all button below the carousel, or an arrow beside its header. That is a composition, not a prop:

<section aria-labelledby="recent-heading">
  <h2 id="recent-heading">Recent</h2>
  <Carousel aria-labelledby="recent-heading" preferredItemWidth={186} items={photos} />
  <Button variant="text" onClick={() => router.push('/photos')}>
    Show all
  </Button>
</section>

The requirement does not apply to the full-screen layout, which already scrolls the same axis as the page.

Behavior

The carousel is a real scroll container, so gestures, wheel, momentum, keyboard scrolling, and right-to-left come from the browser. Snapping is CSS scroll snap positioned at Material's own keylines, so a released gesture settles where the arrangement says it should. Fling distance is the browser's — Material's one-item-at-a-time fling has no web equivalent.

Item masking is computed from the scroll position, which is what makes items expand and collapse between the large, medium, and small widths and gives the image inside a mask its parallax.

Under prefers-reduced-motion: reduce the masking is withdrawn: every item stays at its full size, nothing expands, and the items reach the container edges — the reduced-motion presentation Material describes.

Tokens

Carousel is the one component whose tokens change the layout, not only the paint. Four of them feed the arrangement algorithm directly:

The rest are ordinary appearance tokens: container-color, item-shape, item-container-color, item-content-color, item-spacing, leading-padding, trailing-padding, block-padding, uncontained-trailing-padding, full-screen-padding, full-screen-item-spacing, the focus-ring trio, the state-layer colour, and the two disabled opacities. Override any of them on the theme or on one instance:

<Carousel
  aria-label="Covers"
  preferredItemWidth={186}
  items={covers}
  style={{ '--m3e-comp-carousel-item-shape': '12px' }}
/>

Layout notes

Give the carousel a height. Items fill it, and the multi-aspect layout derives each item's width from that height and the item's ratio.

Item content is laid out at the unmasked item size and clipped, so an image should fill its item — img, video, picture, svg, and canvas children are already sized and cropped for you.
